M16
Category:M16
Keywords:M12 sensor harnesses, M16 industrial equipment harnesses, 5015 military-grade circular connector harnesses, SF bayonet quick-connect waterproof harnesses, and WS snap-lock waterproof harnesses. Our full product line features industrial-grade PUR/PVC jacketed cables with oil resistance and high drag durability, IP67 water protection rating, and an operating temperature range of -40°C to +85°C. Includes M16 circular connectors, M16 field-wireable plugs, M16 over-molded plugs, M16 male/female plugs, M16 panel-mount sockets, M16 square flange sockets, M16 PCB sockets, M16 solder sockets, 2-2 4-pin M16 connectors, IEC 61076-2-106 connectors, IP67 M16 industrial connectors, and M16 dust caps.
Details
Parameters:
Materials and Technical Specifications; Mechanical and Electrical Performance:
| Product Model | M16-2 Pin Waterproof Cable, M16-3 Pin Waterproof Cable, M16-4 Pin Waterproof Cable, M16-5 Pin Waterproof Cable | Use wire | 2-core × 0.75-sq mm PUR-sheathed cable, 3-core × 0.75-sq mm PUR-sheathed cable, 4-core × 0.75-sq mm shielded cable, 5-core × 0.5-sq mm shielded cable |
| Certifications | CE/ROHS IP67 Certified | Use wire | 2-core × 0.75-sq mm PUR-sheathed cable, 3-core × 0.75-sq mm PUR-sheathed cable, 4-core × 0.75-sq mm shielded cable, 5-core × 0.5-sq mm shielded cable |
| Use wire | 2-core × 0.75-sq mm PUR-sheathed cable, 3-core × 0.75-sq mm PUR-sheathed cable, 4-core × 0.75-sq mm shielded cable, 5-core × 0.5-sq mm shielded cable | Operating Temperature | -30°C~90°C |
| Cable Outer Diameter | Approx. 7.0mm, x 7.2mm, x 7.5mm, x 7.8 mm | Operating Temperature | -30°C~90°C |
| Operating Temperature | -30°C~90°C | Wire Color | Red/Black, Brown/Blue/Yellow-Green, Red/Black/Yellow/Green, Red/Black/Yellow/Green |
| Rated Voltage | AC 400V/DC 600V | Wire Color | Red/Black, Brown/Blue/Yellow-Green, Red/Black/Yellow/Green, Red/Black/Yellow/Green |
| Wire Color | Red/Black, Brown/Blue/Yellow-Green, Red/Black/Yellow/Green, Red/Black/Yellow/Green |
