5015
Category:5015
Keywords:M12 sensor harnesses, M16 industrial equipment harnesses, 5015 military-grade circular connector harnesses, SF bayonet quick-connect waterproof harnesses, and WS snap-lock waterproof harnesses—five core product lines. All feature industrial-grade PUR/PVC jacketed cables with oil and drag resistance, IP67 water protection rating, and an operating temperature range of -40°C to +85°C.
Details
5015 Series MIL-SPEC Connector Assemblies, compliant with MIL-DTL-5015, featuring silver high-temperature wire. Available in 2-pin and 3-pin configurations with an outer diameter of approximately 8.0-8.2 mm. Operating temperature range: -55°C to 125°C. Rated voltage: AC 500V/DC700V. Designed for demanding military-grade environments.
Parameters:
Materials and Technical Specifications; Mechanical and Electrical Performance:
| Product Model | 5015 2-pin military harness, 5015 3-pin military harness | Use wire | 2-core × 1.0-sq mm silver high-temperature cable, 3-core × 1.0-sq mm silver high-temperature cable |
| Certifications | MIL-DTL-5015 standard | Use wire | 2-core × 1.0-sq mm silver high-temperature cable, 3-core × 1.0-sq mm silver high-temperature cable |
| Use wire | 2-core × 1.0-sq mm silver high-temperature cable, 3-core × 1.0-sq mm silver high-temperature cable | Operating Temperature | -55°C~125°C |
| Cable Outer Diameter | Approx. 8.0mm, to 8.2mm | Carrying Temperature | -55°C~125°C |
| Operating Temperature | -55°C~125°C | Wire Color | Red/Black, Brown/Red/Yellow |
| Rated Voltage | AC 500V/DC 700V | Wire Color | Red/Black, Brown/Red/Yellow |
| Wire Color | Red/Black, Brown/Red/Yellow |
